  • Journal Highlights

    October 01, 2012

    The following are highlights from the current issues of RSNA's two peer-reviewed journals.

    Radiology journal logo button for Journal Highlights

    Musculoskeletal Tumors: How to Use Anatomic, Functional and Metabolic MR Techniques

    Although the function of MR imaging in the evaluation of musculoskeletal tumors has traditionally been to help identify the extent of disease prior to treatment, its role continues to evolve as new techniques emerge.

    In an article in the October issue of Radiology (RSNA.org/Radiology), Laura M. Fayad, M.D., of Johns Hopkins Medical Institutions in Baltimore, and colleagues discuss a multiparametric approach to evaluating musculoskeletal tumors, focusing on the utility and potential added value of pulse sequences in helping establish a diagnosis, assess pretreatment extent and evaluate tumors in the post-treatment setting for recurrence and treatment response.

    The authors discuss anatomic, functional and metabolic imaging protocols, including chemical shift MR imaging (in-phase and opposed-phase imaging), diffusion-weighted imaging, perfusion imaging and MR spectroscopy, T1-weighted and fluid-sensitive sequences.

    "Although conventional T1-weighted and fluid-sensitive sequences are entirely sufficient to enable determination of the location and extent of a musculoskeletal lesion, quantitative methods now provide metrics that may advance the role of MR imaging to include detection, characterization, and reliable assessment of treatment response," the authors write.

    RadioGraphics logo-button for Journal Highlights

    Imaging of the Female Pelvis through the Life Cycle

    The appearance of the normal reproductive tract on radiologic images changes dramatically over the female patient’s life span, reflecting the influence of hormones on these organs.

    In an article in the October special issue of RadioGraphics (RSNA.org/RadioGraphics), Jill E. Langer, M.D., of the University of Pennsylvania, and colleagues describe expected findings and physiologic changes in the normal female reproductive tract from birth through postmenopausal years, with an emphasis on the appearances of the uterus and ovaries at pelvic ultrasound, CT and MR imaging.

    Whether the female pelvis is imaged because of a suspicion of underlying gynecologic disease or as a screening examination in the asymptomatic patient, radiologists should be familiar with the range of normal appearances in these organs to avoid misinterpreting expected physiologic changes as pathologic conditions and to spare the patient unnecessary additional imaging and surgical or other invasive procedures, according to the authors.

    "A thorough knowledge of how hormonal changes affect the appearance of the uterus and ovaries at pelvic imaging performed in childhood, during the reproductive years, after delivery, and in menopause is important for differentiating expected physiologic changes from pathologic conditions," they write.

    This article meets the critera for AMA PRA Category 1 Credit™. CME is available in print and online.

    black arrowhead 9 x 10 GIF Contact the editor

    Nov_Fayad Figure 1a
    Osteosarcoma of the right femur in a 15-year-old girl. Sagittal T1-weighted MR image (370/10) shows complete replacement of normal fatty marrow signal intensity involving epiphysis and distal metadiaphysis of the right femur. Images obtained with nonenhanced T1-weighted sequence best depict contrast between marrow-replacing tumor and normal fatty marrow for accurately defining extent of the lesion.<BR /> (Radiology 2012;265;2 (In Press) &copy;RSNA, 2012. All rights reserved. Printed with permission.
    RadioGraphics October 2012 Langer figure 15b
    Corpus luteum in a 25-year-old woman. Color Doppler flow image shows marked vascularity only within the wall of the corpus luteum and not in the fluid-containing center. (Radiographics 2012; 32(6):1575-1597) ©RSNA, 2012. All rights reserved. Printed with permission.
